Turkish Journal of Electrical Engineering & Computer Sciences. In Canadian conference on electrical and computer engineering.

Baez-Lopez, D., & Jimenez-Fernandez, V.Analog Integrated Circuits and Signal Processing. A modified low-pass filter with progressively diminishing ripples. In this case study, the frequency (magnitude and group delay) and time (step) responses of the conventional filter are contrasted with those of the modified filter, demonstrating that the experimental results accord with the theoretical background. In order to verify the physical realization capability of this type of filter, the experimental results of a fifth-order Chebyshev filter implemented by using commercially available JFET op-amps TL082 are reported. In our proposal, a synthesis based on FDNR topology (frequency-dependent negative resistor) is preferred over other circuit design strategies due to its low sensitivity. Because most of the references that deal with this topic consider the case of Chebyshev filters, this type of filters is also considered in our experimental validation. This paper is precisely devoted to exploring the viability of physically realizing this idea. However, at present, this idea has only been approached from a theoretical perspective, validated by numerical or electrical simulations but not experimentally verified. The strategy of improving the group delay in analog filters through the modification of conventional characteristic polynomials is a concept reported in advanced filter design literature. The sizes of _B and _A for the second-order sections case are each \(3(L+r)\). If, on the other hand, the format is LIQUID_IIRDES_SOS (second-order sections format) then a few extra steps are needed: define \(r\) as \(0\) when \(N\) is even and \(1\) when \(N\) is odd, and define \(L\) as \((N-r)/2\). If the the format is LIQUID_IIRDES_TF (the regular transfer function format) then the size of _B and _A is simply \(N\).

To compute the specific lengths of the arrays, first define the effective filter order \(N\) which is the same as the specified filter order for low- and high- pass filters, and doubled for band-pass and band-stop filters. The format and size of these arrays depends on the value of the _format and _btype parameters.

_B, _A are the output feed-forward (numerator) and feed-back (denominator) coefficients, respectively.

_As is the stop-band ripple (only applicable to Chebyshev Type-II and elliptic filter designs, ignored for Butterworth, Chebyshev Type-I, and Bessel designs).

_Ap is the pass-band ripple (only applicable to Chebyshev Type-I and elliptic filter designs, ignored for Butterworth, Chebyshev Type-II, and Bessel designs).

_f0 is the normalized center frequency of the analog prototype (only applicable to bandpass and band-stop filter designs, ignored for low-pass and high-pass filter designs).

_fc is the normalized cutoff frequency of the analog prototype.

_format is the output format of the coefficients, e.g.

_ftype is the analog filter prototype, e.g.

Specifically, the interface is liquid_iirdes(_ftype, _btype, _format, _n, _fc, _f0, _Ap, _As, *_B, *_A) The user specifies the filter prototype, order, cutoff frequency, and other parameters as well as the resulting filter structure (regular or second-order sections), and the function returns the appropriate filter coefficients that meet that design. The liquid_iirdes() method designs an IIR filter's coefficients from one of the four major types (Butterworth, Chebyshev, elliptic/Cauer, and Bessel) with as minimal an interface as possible.

Furthermore, if the end result is to create a filter object as opposed to computing the coefficients themselves, the iirfilt_crcf_create_prototype() method can be used to generate the object directly (see ). Externally, the user may abstract the entire process by using the liquid_iirdes() method. Liquid implements infinite impulse response (IIR) filter design for the five major classes of filters (Butterworth, Chebyshev type-I, Chebyshev type-II, elliptic, and Bessel) by first computing their analog low-pass prototypes, performing a bilinear\(z\) -transform to convert to the digital domain, then transforming to the appropriate band type (e.g.
